Use Cases / Case Studies
Explore real-world customer stories across different industries we operate in. Learn how they’re accelerating time to value, optimizing quality and productivity, and reducing operational costs.
Tank Fill Control – Tank Level Monitoring!
1) The Embedos EB Series ( EM Bose ) calcuates the volume of the liquid in the tank & displays its level. The calculation is done based on the inputs from a Pressure sensor that is mounted at the bottom of the tank.
2) The device displays real time values & level of the tank with a view of set points or Threshold Limits between which the liquid of interest should remain.
3) If the Liquid crosses either of the two setpoints, the device sets of a relay which is connected to a high wattage Industrial Lamp ( Bulb ) to indicate that the threshold has been crossed. Also, the device has a buzzer that goes off on the crossing.
IO Data Logger + 4G Gateway
The Embedos IO data logger is designed to log data to device as analog inputs, a pulse input which is to be converted to RPM value. The logger is able to also display real-time data on a webpage based utility.
The user can interact with the data-logger to configure and view all the settings and device parameters currently running on the device. The logger can store real-time data and send the same data via MQTT to a broker.
Dual Channel Analog Data Logger + 7” HMI
Deployment Type: Data Logger +7 Inch HMI Display
“Embedos Engineering – 7 inch Data logger HMI, Model ERA021. (Simultaneous 2 channels)
It has 7 inch touch screen display to monitor sensor data graphically. It has options to start and stop data logging facility.
(External Start Stop for each channel via DI) Has USB port for pen drive connection. You can download the data log in excel format for selected date and time. 2 nos. Digital outputs for set point. – Just NPN outputs.
Can Forklift Controller – Reach Height Display
Deployment Year: 2018
Deployment Type: Data Logger + Display
Problem Statement: In narrow warehouses with high racks, the view and space to maneuver are often restricted.
The Embedos Forklift controller and display based on CAN Bus helps the driver with appropriate displays and assistance systems. This makes load handling safer and more efficient.
CAN-J1939 Data Logger & Modbus – TCP Gateway
This was deployed in 2021, to log a particular set of parameters from a Caterpillar Engine ECU and display logged data.
The Embedos Monitoring Software was used to visualize logged data from the ECU in the form of charts and gauges, display log files in .csv formats and give options & download all log files into the system
Real Time Data Logger with Embedded Web App
Embedos Data Logger + Embedos Expansion IO Card take in an RS-485 input and 4 Analog Inputs Each to display Guages for 8 Analog Channels. Similarly displays a graph of the last 100 values of corresponding channels.
The Embedos Real Time software running on an Embedded Web Server on the master Data logger allows you to download data shown on the table in Excel, CSV or PDF formats directly.
Edge_Glove Test Controller
Deployment Year: 2019 – 2022
Deployment Type: Multiple IO Data Logger + Browser based Web App.
The EDGE as a GLT controller provides an internal Modbus Server to read the analog and Digital inputs and control digital outputs.
EDGE calibration, test and network configuration options have been added to the latest iteration of this application of the EDGE.
Vibration Monitoring Software
The monitoring software stores historical data of each of the vibration units connected to it.
You can view this data in graphical form by right clicking on a card and selecting View History (Alternately, you can also Double Click on a card to open Graph window)
